| Brand Name: | IWAVE |
| Model Number: | FIM-2410 |
| MOQ: | 2units |
| Price: | Negotiable |
| Delivery Time: | 5-8work days |
| Payment Terms: | L/C,D/P,T/T |
10KM HDMI Full HD UAV Video Transmitter And Full Duplex Pixhawk Cube Data Links
Description
FIM-2410 mini transceiver is a new designed TDD-COFDM wireless communication equipment based on military standard for UAVs. It supports 2.3/2.4/2.5Ghz for different environment. The system provides superior performance in 8-12km long range HD video and bi-directional data transmission with 50ms latency.
Key Features
|
 |
FAQ
About video storage
Wireshark can be used to record, Google Wireshark runs on windows. Wireshark can record and playback any video stream on Ethernet. You need to do some research on how to do it, google "wireshark recod play video" and try.
About SDI interface type.
Question 1: Please tell me type of SDI for these links?
Answer: It is standard 3G SDI
Question 2: If I the out put of camera will be to EX_SDI or HD_SDI for out put video of TX link is without noise?
Answer: HD-SDI works with FIM-2450, but EX-SDI doesn't. Because EX-SDI isn't standard SDI, it compresses standard SDI video to JPEG format to transport, standard SDI doesn't compress video.
About Max flight speed
Question: What is the maximum flight speed supported?
Answer: Maximum flight speed supported: 120km/h
Application
Here are the applications listed in English for the specially designed UAV air-to-ground LOS 5km HD video and flight control data transmission system:
Aerial Photography: Capturing high-definition aerial images and videos for professional photography and cinematography purposes.
News Coverage: Providing live video feeds and real-time updates for news reporting and broadcasting.
Sports Events: Recording and transmitting dynamic aerial footage of sports events for enhanced viewing experiences.
Hidden Investigation: Conducting covert surveillance operations with secure and discreet video transmission capabilities.
Video Surveillance: Implementing real-time video monitoring and security solutions for various locations and facilities.
Real-Time Wireless Video Transmission: Enabling the streaming of live video for a wide range of applications, including inspections, remote monitoring, and more.
Additionally, the secure transmission kit is specifically tailored for surveillance drones used in:
Law Enforcement: Supporting law enforcement agencies with secure and reliable aerial surveillance capabilities.
Civil Rescue: Assisting in civil rescue operations by providing real-time video feeds and critical data for effective response and coordination.
Specification
| Frequency | 2.4GHz(2402Mhz-2482MHz) |
| Error Detection | LDPC FEC/Video H.264/265 Super Error Correction |
| RF Transmitted Power | 1W (Air to ground 8km-12km) |
| Power Consumption | TX: 10Watts |
| RX: 6Watts | |
| Bandwidth | 4MHz/8Mhz |
| Latency | ≤15-30ms |
| Transmission Rate | 3-5Mbps |
| Receive Sensitivity | -100dbm@4Mhz |
| Video Color Space | Default 4:2:0 |
| Antenna | 1T2R |
| Video Input/output Interface | HDMI mini TX/RX, or transform FFC to HDMI-A RX/TX |
| Video Compressed Format | H.264+H.265's Algorithms |
| Bit Rate | Software adjustment, Max 115200bps |
| Encryption | AES 128 |
| Transmission Distance | Air to ground 8-12km |
| Start-up time | < 30s |
| Two-way function | Support video and duplex data simultaneously |
| Data | Support bi-directional TTL |
| Power supply | DC 7- 18V |
| Interface | 1080P/60 HDMI Mini RX x1 |
| 100Mbps Ethernet to USB / RJ45 on Windows × 1 | |
| S1 TTL bi-directional serial port x1 | |
| Power Input x1 | |
| Indicator Light | HDMI input/output Status |
| Transmitting and receiving | |
| Video board working Status | |
| Power | |
| HDMI | HDMI mini |
| Temperature Range | Operating temperature:-40°C ~+ 85°C |
| Storage temperature:-55°C ~+ 100°C | |
| Appearance Design | CNC technology/ double aluminum alloy shell |
| Dimension | 72×47×19mm |
| Weight | Tx: 94g/Rx: 94g |
|
|
