| Brand Name: | IWAVE |
| Model Number: | FPM-8416 |
| MOQ: | 2units |
| Price: | Negotiable |
| Delivery Time: | 5-8work days |
| Payment Terms: | L/C,D/P,T/T |
15km Drone HDMI Video Transmitter Ethernet And Bi-directional Data Link
Description
FPM-8416 is a mini COFDM video transmitter offering a video, Ethernet and bi-directional Serial data link specifically designed for commercial and industrial drones for 16km rang.
The FPM-8416 is a compact drone video transmitter equipped with a bi-directional data communication link, tailored to support autonomous functionality for commercial and industrial UAVs. It enables remote, wireless control and real-time video surveillance of the drone from a distance of up to 10 miles. Leveraging the 4th generation mobile communication's COFDM multi-carrier modulation technology at its core, it delivers exceptional security and robust performance even in adverse conditions.
Key Features
|
 |
Application
The miniature 130g UAV drone video link has found applications in numerous sectors due to its compact size and lightweight design. Here is a list of its main applications:
Police Forces and First Responders:
Security Services:
Oil Pipeline Inspection:
Specification
| Specifications | |||
| Frequency | 800Mhz | 806~826 MHz | |
| 1.4Ghz | 1428~1448 MHz | ||
| Bandwidth | 8MHz | ||
| RF Power | 0.6watt(Bi-Amp, 0.6watt Peak Power of each power amplifier) | ||
| Transmit Range | 800Mhz: 16km1400Mhz: 14km | ||
| Antenna | 800Mhz | TX:Omni Antenna/25cm Length/ 2dbiRX:Omni Antenna/60cm Length/6dbi | |
| 1.4Ghz | TX:Omni Antenna/35cm Length/3.5dbiRX:Omni Antenna/60cm Length/5dbi | ||
| Transmit Rate | 3Mbps (HDMI Video Stream, Ethernet Signal and serial data share) | ||
| Baud Rate | 115200bps(Adjustable) | ||
| Sensitivity | -106@4Mhz | ||
| Wireless Fault Tolerance Algorithm | Wireless baseband FEC forward error correction/ video codec super error correction | ||
| End to End Latency | Latency for encoding + transmission + decoding 720P/60 <50 ms 1080P/60 <80ms |
||
| Link Rebuild Time | <1s | ||
| Modulation | Uplink QPSK/Downlink QPSK | ||
| Video Compression | H.264 | ||
| Video Color Space | 4:2:0 (Option 4:2:2) | ||
| Encryption | AES128 | ||
| Start Time | 15s | ||
| Power | DC12V (7～18V) | ||
| Interface | Interfaces on Tx and Rx are same Video input/Output: Mini HDMI*1 Power Input Interface*1 Antenna Interface:SMA*2 Serial*1: (Voltage:+-13V(RS232), 0~3.3V(TTL)² Ethernet: 100Mbps x 3 |
||
| Indicators | Power Wireless Connection Setup Indicator |
||
| Power Consumption | Tx: 9W(Max)Rx: 6W | ||
| Temperature | Working: -40 ~+ 85℃Storage: -55 ~+100℃ | ||
| Dimension | Tx/Rx: 93 x 55.5 x 23.5 mm | ||
| Weight | Tx/Rx: 130g | ||
| Metal Case Design | CNC technology/ double aluminum alloy shell | ||
| Double Aluminum Alloy Shell | |||
| Conductive anodizing craft | |||
|
|
