Key Features:

1. Frequency-Hopping Spread Spectrum (FHSS)

   IWAVE IP MESH product will internally calculate and evaluate the current link based on factors such as received signal strength RSRP, signal-to-noise ratio SNR, and bit error rate SER. If its judgment condition is met, it will perform frequency hopping and select an optimal frequency point from the list.

   Whether to perform frequency hopping depends on the wireless state. If the wireless state is good, frequency hopping will not be performed until the judgment condition is met.

2. Mesh Network Flexibility: The FD-6100 can support up to 32 nodes on a single frequency MESH network. This enables dynamic communication among multiple devices, essential for applications where numerous UAVs or UGVs need to coordinate with each other.

3. Simultaneous Data Types: The ability to transmit both IP and Serial data simultaneously is critical for systems that need to handle various types of communication, such as controlling hardware and transmitting high-definition video feeds.

4. Security: The 128/256-bit AES encryption ensures secure communication, an essential feature for military, law enforcement, or other high-security applications.

5. Low Latency: With latency under 25ms, the FD-6100 is well-suited for real-time control and data processing, such as live video streaming or telemetry in mission-critical scenarios.

6. Web UI for Configuration:IWAVE self-developed MESH network management software will real time show you the topology, RSRP, SNR, distance, IP address and other information of all the nodes. The software is WebUi based and you can login it anytime anywhere with IE browser. From the software, you can configure the settings per your requirement, such as working frequency, bandwidth, IP address, dynamic topology, real time distance between nodes, algorithm setting, up-down sub-frame ratio, AT commands, etc.
