| Brand Name: | IWAVE |
| Model Number: | FD-6100 |
| MOQ: | 2 |
| Price: | Negotiable |
| Delivery Time: | 3-5working days |
| Payment Terms: | L/C,D/P,T/T |
Fluid Self-Healing Mesh: This allows the FD-6100 to create a reliable, resilient communication network that can adapt dynamically to changes in the topology, which is particularly beneficial for mobile platforms like UAVs and UGVs.
High Data Rates: The 30 Mbps (Uplink + Downlink) data rate ensures that high-quality video streaming and telemetry data can be transmitted seamlessly, making it ideal for surveillance, monitoring, and other data-intensive tasks.
Tri-band Frequency: The ability to switch between 800MHz, 1.4GHz, and 2.4GHz bands allows for flexible operation in different environments, overcoming potential interference and optimizing the communication link based on available frequencies.
Long Range: With a line-of-sight (LOS) range of up to 10 km for UAVs, it supports extended operational distances, which is critical for applications like border surveillance, search-and-rescue, or long-range reconnaissance.
Adjustable Output Power: The adjustable RF power range (-40dBm to +25dBm) allows for flexible tuning of transmission power, providing optimal signal strength for various environments while also helping to conserve battery life.
Surveillance & Video Broadcasting: Due to its long-range, high-speed capabilities, and low-latency communication, the FD-6100 is ideal for live video feeds and real-time telemetry in both aerial and ground-based surveillance missions.
Search and Rescue: The flexible mesh networking, long range, and secure communication make it a valuable tool for search and rescue operations, especially in difficult-to-reach areas.
Military and Defense: The encryption and robust communication capabilities suit military UAV/UGV operations for secure and reliable communications in tactical environments.
Remote Monitoring: The ability to stream video and telemetry while maintaining a stable link in harsh environments makes it perfect for remote environmental monitoring or industrial inspections.
| GENERAL | ||
| TECHNOLOGY | MESH base on TD-LTE Wireless technology standard | |
| ENCRYPTION | ZUC/SNOW3G/AES(128) OptionalLayer-2 | |
| DATA RATE | 30Mbps(Uplink and Downlink) | |
| RANGE | 10km(Air to ground)500m-3km(NLOS Ground to ground) | |
| CAPACITY | 16nodes | |
| POWER | 23dBm±2 (2w or 10w on request) | |
| LATENCY | One Hop Transmission≤30ms | |
| MODULATION | QPSK, 16QAM, 64QAM | |
| ANTI-JAM | Automatically Cross-Band frequency hopping | |
| BANDWIDTH | 1.4Mhz/3Mhz/5Mhz/10MHz/20MHz | |
| POWER CONSUMPTION | 5Watts | |
| POWER INPUT | DC12V | |
| SENSITIVITY | ||
| 2.4GHZ | 20MHZ | -99dBm |
| 10MHZ | -103dBm | |
| 5MHZ | -104dBm | |
| 3MHZ | -106dBm | |
| 1.4GHZ | 20MHZ | -100dBm |
| 10MHZ | -103dBm | |
| 5MHZ | -104dBm | |
| 3MHZ | -106dBm | |
| 800MHZ | 20MHZ | -100dBm |
| 10MHZ | -103dBm | |
| 5MHZ | -104dBm | |
| 3MHZ | -106dBm | |
| FREQUENCY BAND | ||
| 2.4Ghz | 2401.5-2481.5 MHz | |
| 1.4Ghz | 1427.9-1447.9MHz | |
| 800Mhz | 806-826 MHz | |
| COMUART | ||
| Electrical Level | 2.85V voltage domain and compatible with 3V/3.3V level | |
| Control Data | TTL mode | |
| Baud rate | 115200bps | |
| Transmission Mode | Pass-through mode | |
| Priority level | Higher priority than the network portWhen the signal transmission is crowed, the control data will be transmitted in priority |
|
| Note:1. The data transmitting and receiving is broadcast in the network. After successful networking, each FD-6100 node can receive serial data. 2. If you want to distinguish between sending, receiving and control, you need todefine the format yourself |
||
| MECHANICAL | ||
| Temperature | -40℃~+80℃ | |
| Weight | 50grams | |
| Dimension | 7.8*10.8*2cm | |
| Stability | MTBF≥10000hr | |
| INTERFACES | ||
| RF | 2 x SMA | |
| ETHERNET | 1xEthernet | |
| COMUART | 1x COMUART | |
| POWER | DC INPUT | |
| INDICATOR | Tri-COLOR LED | |
Interface
