| Brand Name: | IWAVE |
| Model Number: | Knight-F10 |
| MOQ: | 1Unit |
| Price: | Negotiable |
| Delivery Time: | 5-8work days |
| Payment Terms: | L/C, D/P, T/T |
High Power Outdoor Industrial Grade LTE Customer Premises Equipment CPE
Descryption
CPE configures LTE and Wi-Fi modules inside, so that it can access LTE network through the LTE module in the uplink, and provide Wi-Fi access function through the WiFi module in the downlink.
It is applied for mobile or fixed installation scenes, which require forwarding LTE private network signals via wired and wireless routers.
The industrial-grade outdoor CPE gateway is used for outdoor installation to convert the network of the base station into a wireless network, providing high-definition audio and video image transmission and data service transmission for the terminal, or for wireless interconnection and networking between the base station and the base station. The 10W CPE can provide a longer wireless transmission distance.
Key Features
|
High Performance |
 |
Specifications
| Model | Knight-F10 |
| Network Technology | TD-LTE |
| Frequency Band | 400M/600M/1.4G/1.8G |
| Channel bandwidth | 20MHz/10MHz/5MHz |
| Number of channels | 1T2R,support MIMO |
| RF Power |
10W(optional)
|
| Receiving sensitivity | ≮-103dBm |
| Throughout | UL:≥30Mbps,DL:≥80Mbps |
| Interface | LAN,WLAN |
| levels of protection | IP67 |
| Power | 12V DC |
| Temperature (operating) | -25°C ~ +55°C |
| Humidity(operating) | 5%~95% RH |
| Air pressure range | 70kPa～106kPa |
| Installation method | Support outdoor installation, pole installation, wall installation |
| Heat dissipation method | Natural heat dissipation |
|
|
| Brand Name: | IWAVE |
| Model Number: | Knight-F10 |
| MOQ: | 1Unit |
| Price: | Negotiable |
| Packaging Details: | Standard Carton Box |
| Payment Terms: | L/C, D/P, T/T |
High Power Outdoor Industrial Grade LTE Customer Premises Equipment CPE
Descryption
CPE configures LTE and Wi-Fi modules inside, so that it can access LTE network through the LTE module in the uplink, and provide Wi-Fi access function through the WiFi module in the downlink.
It is applied for mobile or fixed installation scenes, which require forwarding LTE private network signals via wired and wireless routers.
The industrial-grade outdoor CPE gateway is used for outdoor installation to convert the network of the base station into a wireless network, providing high-definition audio and video image transmission and data service transmission for the terminal, or for wireless interconnection and networking between the base station and the base station. The 10W CPE can provide a longer wireless transmission distance.
Key Features
|
High Performance |
|
Specifications
| Model | Knight-F10 |
| Network Technology | TD-LTE |
| Frequency Band | 400M/600M/1.4G/1.8G |
| Channel bandwidth | 20MHz/10MHz/5MHz |
| Number of channels | 1T2R,support MIMO |
| RF Power |
10W(optional)
|
| Receiving sensitivity | ≮-103dBm |
| Throughout | UL:≥30Mbps,DL:≥80Mbps |
| Interface | LAN,WLAN |
| levels of protection | IP67 |
| Power | 12V DC |
| Temperature (operating) | -25°C ~ +55°C |
| Humidity(operating) | 5%~95% RH |
| Air pressure range | 70kPa～106kPa |
| Installation method | Support outdoor installation, pole installation, wall installation |
| Heat dissipation method | Natural heat dissipation |
